CREATBOT MALAYSIA · PROFESSIONAL HIGH-SPEED FDM
Industrial-grade FDM printing on a desktop — the 420 × 400 × 420 mm build chamber, dual 420 °C extruders and 600 mm/s motion of the best-selling D600 Pro3 HS, in a machine that fits your workshop.
The D400 HS is developed on the identical platform as the world's best-selling D600 Pro3 HS — the same structural architecture, Klipper motion system and high-flow hotend, sized for the desktop.
Large-format prints live or die on their first layer. The D400 HS uses automatic mesh bed leveling with eddy-current sensing to map the entire platform before every job — contact-free, zero wear, no feeler gauges.
A flat, consistent first layer is also what lets 600 mm/s speeds actually pay off — no failed adhesion, no re-slicing, no wasted spools.
The mechanics behind a stable 600 mm/s — every subsystem tuned for uptime, not just a speed number.
An HD macro camera aligns XY to 0.02 mm and dual photoelectric sensors set Z to 0.005 mm — hands-off, every tool change.
A mechanical shutter seals the idle nozzle the instant it lifts, stopping ooze and cross-contamination in multi-material prints.
Heat to 400 °C in about two minutes with ±0.15 °C stability; hotends swap for 0.3–1.0 mm nozzles.
Double-layer insulation holds chamber heat for PC, ABS, ASA and PA-CF — less warping, stronger layer bonding.
Sensors and systems that keep long prints running — the difference between a prototype machine and a production machine.
0.005 mm nozzle-height verification with multi-point positioning — Z stays right even after nozzle swaps.
The coated steel sheet pops off by hand and won't demagnetise — big parts release flat, fast.
A medical-grade pump pushes constant air across the part with minimal noise — rated for 24/7 operation.
A dual filter captures fine particles and VOCs at 99.995% adsorption — cleaner air for the operator and the workshop.
Power cuts save position and print data and resume on restart; filament run-out pauses; backup mode switches nozzles to finish the job.
Eddy-levelled first layers, a rigid steel frame and a lightweight printhead — the D400 HS holds detail at full speed.
0.00375 mm XY positioning precision with a 60-second full-platform scan before every job.
The topologically optimised lightweight printhead keeps corners and embossed detail crisp at 600 mm/s.
Engineering-grade filaments printed full-size on the 420 × 400 × 420 mm platform.
Two extruders with soluble or breakaway supports — complex geometry without compromise.
All-steel hotends, nozzle and chamber to 420 °C — from everyday PLA to PPS-CF and UltraPA-CF engineering filaments. Tell us your material and we will share the print profile.
Delivery, installation and first-print commissioning across Peninsular Malaysia — Sabah and Sarawak by arrangement.
On-site or online onboarding: slicer workflow, material profiles, chamber recipes and calibration routines for your parts.
Nozzles, hotends, filters, plates, belts and common consumables kept locally — not ordered from overseas.
Maintenance and print-quality troubleshooting from a team that runs industrial FDM machines every working day.
Serving Kuala Lumpur, Selangor, Penang, Johor, Ipoh, Kuantan, Kota Kinabalu and Kuching.
Everything below is the manufacturer's published specification for the machine we supply and install.
| Print technology | FDM / FFF, dual extruder |
|---|---|
| Build volume | 420 × 400 × 420 mm Dual extrusion: 365 × 400 × 420 mm |
| Number of nozzles | Two, auto-raising |
| Layer resolution | 0.05 mm |
| Nozzle diameter | 0.6 mm standard 0.3 / 0.4 / 0.8 / 1.0 mm optional |
| Filament diameter | 1.75 mm |
| Materials | PLA, ABS, ASA, PP, PETG, PC, Nylon, TPU and CF/GF engineering grades — see the list above |
| Max print speed | 600 mm/s |
|---|---|
| Flow rate | 90 mm³/s |
| Max nozzle temperature | 420 °C |
| Max bed temperature | 120 °C |
| Chamber temperature | 70 °C active heating |
| Thermostat accuracy | ±0.15 °C |
| XY positioning precision | 0.00375 mm |
| Z positioning precision | 0.00156 mm |
| Firmware | Klipper — high speed |
|---|---|
| Display | 7-inch touchscreen |
| Slicers | CreatWare, Orca Slicer, Cura, Simplify3D, PrusaSlicer |
| File types | Gcode, STL, 3MF, OBJ, AMF, STP, STEP |
| Operating systems | Windows / macOS |
| Connectivity | WiFi, LAN, USB — full offline control supported |
| Camera control | Remote monitoring, speed / pause / temperature |
| Door detection | Yes — pauses when opened |
| Machine size | 785 × 705 × 1020 mm |
|---|---|
| Machine weight | 110 kg |
| Packing size & weight | 860 × 790 × 1220 mm, 150 kg |
| Power requirements | 210–240 V (or 100–120 V depending on region) |
| Rated power | 3200 W at 210–240 V |
| Build plate | Aviation aluminium with removable magnetic sheet, automatic leveling |
| Air filter | HEPA + activated carbon, 99.995% adsorption |
Manual: CreatBot D400 HS user manual (English, PDF) — official manufacturer documentation.
Films from CreatBot's official channel, plus demonstrations of the D400 HS systems on this page — clips play on hover or tap.
Professional, large-format prototyping and production: functional prototypes, tooling, jigs & fixtures, moulds and end-use parts — especially when engineering-grade materials are required.
With a stable 600 mm/s and a 90 mm³/s peak flow, the D400 HS can deliver up to 5× faster output than conventional machines — large prototypes and production parts move from days to hours.
Yes. The 420 °C hotend, 120 °C bed and 70 °C heated chamber handle PA-CF, PA-GF, nylon, PC, ABS, ASA, PET-CF, PPS-CF and similar engineering filaments reliably.
Yes. The 7-inch touchscreen, Klipper-based firmware, automatic mesh bed leveling and full-auto dual-nozzle calibration mean a standard engineer can be up and running quickly with minimal training.
Yes. Optimised Klipper motion control, the lightweight printhead, real-time anti-tilt Z correction and 0.001 mm eddy-current leveling keep dimensional accuracy and surface finish excellent even at 600 mm/s.
Multi-material and multi-colour prints, soluble or breakaway supports for complex geometry, and a backup mode that switches to the second nozzle if the first runs out of filament. The automatic nozzle shutter prevents oozing and cross-contamination.
The 70 °C active chamber minimises thermal stress, warping and delamination in ABS, ASA, PA-CF, nylon and PC, and reduces moisture effects on hygroscopic filaments — stronger parts with repeatable results.
Price depends on the configuration: machine, nozzle set and any accessories, plus delivery, installation and operator training. Request a quote and we will send a complete Malaysian quotation.
Yes. Bring a part file or sample to our Kuala Lumpur showroom and we will print it in front of you, or ask for an on-site demo at your premises. See the D600 Pro3 HS and D1000 Pro HS while you are there.
Harga bergantung pada konfigurasi mesin, set nozzle dan aksesori, termasuk penghantaran, pemasangan dan latihan operator. Hubungi kami untuk sebut harga lengkap di Malaysia.
Ya — ruang binaan 420 × 400 × 420 mm dengan kebuk panas 70 °C membolehkan prototaip dan alat pengeluaran dicetak sendiri menggunakan bahan kejuruteraan seperti PA-CF dan PC. Kami menyediakan pemasangan, latihan dan sokongan tempatan.
Tell us what you print — material, part size and volume — and we will quote the D400 HS configured for your workshop, including delivery, installation and operator training in Malaysia. Prefer to see it first? Book a demo in Kuala Lumpur and bring a part file.
Prefer to talk first? Contact our team or WhatsApp us — or browse the rest of the CreatBot range, including the D600 Pro3 HS and D1000 Pro HS.
