FORMLABS MALAYSIA · LARGE-FORMAT MASKED SLA (MSLA) RESIN 3D PRINTER
Large-format resin printing at LFD speed — a 24.2-litre build volume that takes full-size parts in one piece, large prints finished in under 6 hours, and the same 46 µm precision as the Form 4, from a machine anyone can learn in 15 minutes.
The Form 4L scales Formlabs' Low Force Display engine up to large-format parts — full-size prototypes, moulds and production tools leave the printer in hours, not the overnight-plus runtimes of large-format FDM and older SLA.
Form 4L keeps the print-engine principles of the Form 4 and grows them. The Backlight Unit now uses 145 uniform-wavelength LEDs behind a plano-convex lens array, delivering 405 nm light at 16 mW/cm² to the cure plane, while the Light Processing Unit 4L patterns down to a 46 µm pixel — so big parts keep fine detail and sharp edges across the whole platform.
Large-format printing usually means compromise — the Form 4L is the exception: full-size parts at the fidelity the Form 4 made normal.
Moulds, brackets, panels and production fixtures at resin quality — without large-format FDM runtimes.
Large prints finish in under 6 hours — and print time stays nearly the same whether the platform holds one big part or a full plate of smaller ones.
4.6× the Form 4 — a 353 × 196 × 350 mm envelope for full-size parts, deep housings and multi-part nests in one job.
Mould halves, forming tools and jigs printed in hours for in-house production — iterate a tool overnight, back in production by morning.
Threaded inserts, motor housings and load-bearing brackets in tough engineering resins — parts that go straight onto the machine.
Full-scale components with the finish and tolerance to assemble first time — printed parts measured against CAD, not eyeballed.
Clear Resin prints light guides, fluidic manifolds and transparent housings at full size, in one piece.
A full seat prototype in a single build — the class of part that used to be split into sections and bonded back together.
The Form 4L runs the same four-step rhythm as every Formlabs printer — prepare, print, wash and cure, then finish — with the heavy lifting automated in PreForm and Dashboard.
New operators are productive on day one — large-format printing without the specialist overhead.
Sharpest details, smoothest surfaces, accurate assemblies — at more than four times the size.
46 µm pixel size with pre-tuned anti-aliasing resolves fine features and sharp edges across the full build area.
Lower peel forces and light-touch supports leave surfaces clean enough to rival moulded parts.
±0.15% XY tolerance on 1–30 mm features — large parts and their mating components fit the first time.
Flexible-film tanks, dual cartridges and light-touch supports keep running costs and material waste down.
Measured against CAD after printing — large parts arrive straight into assembly, not into rework.
Validated settings, six control sensors and remote monitoring keep the Form 4L productive day after day.
Every Formlabs resin ships with settings validated in-house — a proven recipe for each material, no experimentation required.
Six upgraded sensors watch resin temperature, level, print forces and status — catching issues before they become failed prints.
Watch jobs from anywhere via Dashboard, with the integrated 5 MP camera capturing timelapses of every build.
145 backlight LEDs behind a collimating lens array deliver identical light across the whole platform — edge-to-edge consistency on big parts.
The release texture and flexible-film tank cut peel forces print after print, protecting both the part and the film.
Form Wash L cleans and Form Cure L precision-cures full-platform parts, so finishing never becomes the bottleneck.
Full-size parts for aviation, automotive, research and production — in 19 Formlabs materials or qualified third-party resins via Open Material Mode.
Interior panels, ducting and fit-check parts printed at full scale.
Interior components, clips and test rigs in production-representative resins.
Full trays of end-use parts and machine components, printed together and used as-printed.
Printed guides and fixtures working inside production machinery — parts that earn their keep around the clock.
Marine hardware and long parts that used to need splitting, bonded and put to work.
Lab-scale structures, fluidic parts and test components for research programmes.
19 Formlabs materials at launch — rigid, tough, elastic, silicone, castable, ceramic and flame-retardant chemistry, with new materials in development — or qualified third-party resins via Open Material Mode. Ask us for material advice for your application.
Form 4L, Form Wash L and Form Cure L delivered, installed and commissioned — Peninsular Malaysia; Sabah and Sarawak by arrangement.
Onboarding for your team: PreForm workflow, resin handling, support removal, wash and cure routines — typically a single session.
Resin cartridges, tanks, build platforms and finishing tools — stocked locally so your printer never waits for supplies.
Print-quality troubleshooting and maintenance from a team that runs professional resin printers every working day.
Serving Kuala Lumpur, Selangor, Penang, Johor, Ipoh, Kuantan, Kota Kinabalu and Kuching.
Manufacturer's published specification for the machine we supply, install and support in Malaysia.
| Technology | Masked Stereolithography (MSLA) |
|---|---|
| Printer engine | Low Force Display™ (LFD) |
| Key components | Backlight Unit, Light Processing Unit 4L, Release Texture, flexible-film resin tank, intelligent control systems, automatic resin handling |
| Light source | 145 uniform-wavelength LEDs, plano-convex lens array, integrated air cooling 405 nm · 16 mW/cm² at the cure plane · 46 µm pixel |
| Layer thickness | 25–200 µm |
| XY resolution | 46 µm with pre-tuned anti-aliasing for subpixel resolution |
| Resin handling | Two next-generation cartridges, automatic dispensing, 5–10× faster filling, 63% less waste |
| Resin heating | High-speed conduction heating with infrared sensing, 25–45 °C |
| Force sensing | Z-axis force sensor — optimises quality and speed per geometry |
| Maximum print speed | 80 mm/hour |
|---|---|
| Typical print speed | 24 mm/hour average across materials (20–35 mm/hour by material) |
| Large prints | Finished in under 6 hours |
| XY tolerances | 1–30 mm features: ±0.15% (min ±0.02 mm) 31–80 mm: ±0.3% (min ±0.06 mm) · 81–150 mm: ±0.3% (min ±0.15 mm) |
| Build volume | 353 × 196 × 350 mm — 24.2 litres |
| Build area | 692 cm² |
| Surface accuracy | With Precision Model Resin: 99.9% of surfaces within 100 µm of CAD |
| Printer dimensions | 664 × 528 × 794 mm |
|---|---|
| Minimum access | 889 × 1169 × 813 mm |
| Printer weight | 58.5 kg |
| Operating environment | 18–28 °C |
| Power requirements | 100–240 VAC, 9 A, 50/60 Hz, 900 W |
| Connectivity | Wi-Fi (2.4/5 GHz), Gigabit Ethernet, USB-C |
| Display | 7-inch interactive touchscreen, 1280 × 800, multilingual |
| Camera | 5 MP (2592 × 1944) — remote monitoring, print history, timelapses |
| Sensors | Six systems: infrared resin temperature, ultrasonic resin level, Z-axis force, cartridge load cell, leveling sensor, camera |
| Alerts | Touchscreen, SMS/email via Dashboard, audio |
| Software | PreForm, Dashboard |
|---|---|
| File input / output | STL, OBJ, 3MF input · FORM output |
| PreForm features | One-click print, adaptive layer thickness, remote print, auto-orient, auto-mesh repair, advanced support editing |
| System requirements | Windows 10+ (64-bit) or macOS 13+, 4 GB RAM (8 GB recommended) |
| Materials | 19 Formlabs materials — rigid, tough, flexible, clear, high temp, flame retardant, castable, ceramic and more — or third-party resins via Open Material Mode |
| Biocompatible | Available on Form 4BL |
| Ecosystem | Form Wash L (cleaning), Form Cure L (post-curing) |
Brochure: Formlabs Form 4 / Form 4L SLA ecosystem sell sheet (PDF) — official manufacturer document.
*Large prints in under 6 hours per manufacturer testing; comparison figures as published by Formlabs.
Official films from Formlabs — the large-format workflow end to end, how the LFD engine works, unboxing and setup, and the Form 4 / Form 4L introduction.
The Form 4L's 353 × 196 × 350 mm (24.2-litre) build volume is 4.6× the Form 4 — full-size prototypes, ducts, seat-scale parts, large moulds and jigs that simply do not fit a desktop envelope, printed in one piece.
Large prints finish in under 6 hours. Maximum print speed is 80 mm/hour, with an average of 24 mm/hour across materials, and print time stays nearly the same whether you print one big part or many at once.
46 µm XY pixel size with pre-tuned anti-aliasing, ±0.15% XY tolerance on 1–30 mm features (±0.3% on larger features), and low peel forces with light-touch supports for surfaces that rival moulded parts.
19 Formlabs materials at launch — rigid, tough, flexible, clear, high-temperature, flame-retardant, castable and ceramic chemistry, with more in development — plus qualified third-party resins via Open Material Mode. Two next-generation cartridges load at once for automatic dispensing.
Parts are washed and post-cured for full material properties. Form Wash L and Form Cure L are sized for the Form 4L platform — we supply, install and support both alongside the printer.
PreForm for print preparation — one-click print, auto-orientation, auto-supports, mesh repair and live printability checks on large parts — plus Dashboard for fleet management, remote monitoring and timelapses.
It carries the same control architecture as the Form 4 platform: validated print settings material by material, six upgraded sensors, factory calibration and long-lasting consumables. Ask us for the latest reliability figures.
If your parts fit within 200 × 125 × 210 mm, the Form 4 is the faster, more affordable option. For full-size parts, large moulds and jigs, or batches of big components, the Form 4L prints them in one piece. Send us your files and we will help you pick.
Price depends on configuration: printer, resin starter selection, Form Wash L and Form Cure L options, plus delivery, installation and operator training. Request a quote and we will send a complete Malaysian quotation with lead time.
Yes — send us your part file and application details. We will recommend the right resin, workflow and configuration for your team, and quote the complete setup for Malaysia.
Harga bergantung pada konfigurasi: pencetak, pilihan resin, Form Wash L dan Form Cure L, termasuk penghantaran, pemasangan dan latihan operator. Hubungi kami untuk sebut harga lengkap di Malaysia.
Ya — saiz binaan 353 × 196 × 350 mm dan resolusi 46 µm membolehkan komponen besar dicetak dengan tepat untuk kegunaan industri. Kami menyediakan pemasangan, latihan dan sokongan tempatan untuk pasukan kejuruteraan dan pembuatan.
Tell us what you need to print — part size, application and material — and we will quote the Formlabs Form 4L configured for your workflow, including Form Wash L, Form Cure L, delivery, installation and operator training in Malaysia. Have a part in mind? Send us the file and we will advise on the right resin and print settings for it.
Prefer to talk first? Contact our team or WhatsApp us — or browse our SLA 3D printers and the rest of the Formlabs range.
